Android Panel PC
Android Panel PC
Uinda K-Series Android Panel PC is made from industrial grade components and ideal for various applications such as outdoor kiosks, information display systems, transportation scheduling, multimedia advertising, and industrial control, among many others. these compact devices are equipped with several useful features to withstand the demanding conditions of industrial applications.
- Aspect Ratio: 16:09
- Size: 23.8"
- Color: silver
- TouchScreen：10-point capacitive touch screen
- Standard: Intel® Celeron J4125 / 8G DDR4 / 6*COM
- Customized: J4125/RK3568/RTD2522
Windows
Android
Monitor
Android Panel PC Description
Uinda’s K-Series Android Panel PC is a 23.8″ fanless panel PC in a compact form factor. It runs on the Android platform. Android Panel PC comes with a multi-touch projected capacative touchscreen, With its compact size and optional PoE capabilities, it is perfect for applications such as digital signage, restaurant table-top displays, building intercom systems, room access, room scheduling, building automation, home automation, building security, and lighting control.
Android Panel PC Product Picture
Android Panel PC Spec
| Name | Android Panel PC | |
| Display | Screen size | 23.8 inche |
| Resolution | 1920*1080 | |
| Brightness | 350 cd/m2 | |
| Colour | 16.7M | |
| Ratio | 1000:1 | |
| visual Angle | 89/89/89/89 (Typ.)(CR≥10) | |
| Display area | 527.04(W) *296.46(H)mm | |
| Touch Feature | Type | Capactive |
| Communication mode | USB communicate | |
| Touch method | Fingure/Capactive pen | |
| Touch life | Capactive＞50 Milion | |
| luminousness | >87% | |
| Surface hardness | ＞7H | |
| Glass type | Chemically enhanced plexiglass | |
| Hardware SPEC | Mainboard model | RK3568 |
| CPU | RK3568，Cortex-A55 2.0GHz | |
| RAM | 2G（4G/8G Optional） | |
| ROM | 16G（MAX 128G optional） | |
| System | Android 11 | |
| 4G MODULE | available | |
| WIFI | WIFI-2.4G（optional WIFI-5.0G） | |
| BT | BT-4.1 | |
| GPS | available | |
| MIC | available | |
| RTC | Support | |
| Wake on LAN | Support | |
| Timing switcher | Support | |
| System upgrade | USB upgrade | |
| Interface | MB Power1 | 1*DC12V/5521 |
| MB Power2 | 1*Wide voltage power supply 9~36V CLIPLINE（optional） | |
| HDMI | 1*HDMI | |
| USB-OTG | 1*USB3.0 | |
| USB-HOST | 1*USB2.0 | |
| TF Slot | 1*TF | |
| RJ45 | 1*1000M | |
| SIM Slot | 1*SIM | |
| RS232 | 2*RS232 | |
| RS485 | 1*RS485（optional） | |
| Audio | 1*3.5mm | |
| Feature | Material | CNC Sand blasting oxidation process of aluminum alloy |
| Colour | Blackc | |
| Adapter Input | AC 100-240V 50/60Hz CCC、CE certificate | |
| Power input | DC12V / 4A | |
| Power consume | ≤25W | |
| Backlit life | 50000h | |
| Environment temp | Function temp：-10-60℃，Storage temp：-20-70℃ | |
| Humidity | ≤95% | |
| installation | Embedded/Wallmounted/Foldable stand/Cantilever mounting | |
| Warranty | 12 month | |
| Maintenance | Post | |
| Dimension | 597*373*68mm | |
| installation frame size | 579*355mm | |
| Power cable | 1*Power cable1.2M | |
| Power adapter | 1*Power adapter1.2M | |
| QC Certificate | 1*QC certificate | |
| Warranty | 1*Warranty | |
Android Panel PC Solution
Industrial Automation and Monitoring
In the factory production line, as the equipment monitoring and control terminal, providing stable, real-time data acquisition and remote regulation.
Commercial Retail & POS System
Applied to retail shops and catering establishments, it supports ordering, cashiering and inventory management with easy operation and quick response.
Medical Health and Remote Monitoring
Used for data collection, display and remote medical monitoring in hospitals or clinics to ensure accurate and timely transmission of information.
Education, Training and Public Information Terminal
Used for interactive learning and digital signage display in schools, exhibitions or public places to enhance the efficiency of information delivery.
UInda's industrial Android Panel PC are used in a wide range of applications such as: Restaruant, Advertisement, Gaming, Medical Equipment, kiosk, ATM, Industrial autamation, Supermarket chain stores etc.
Uinda Android Panel PC has a minimum MOQ of 1 piece and supports customisation.
Yes, our Android Panel PC support the customization with size, Logo, function, appearance, resolution, high brightness and etc.
Our Android Panel PC have siet: 7" 8" 10.1” 10.4“ 11.6” 12.1“ 13.3” 15.6“ 17.3” 18.5“ 19” 21.5“ 23.8”. We also support the customized.
